Rahmen
- Carbon HMF
- Integrated Suspension Technology
- Virtual 4 Link kinematic / Adjustable head angle
- Syncros Cable Integration System
- TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
- Range Extender Ready
Federweg
- Front: 160mm
- Rear: 155mm
Gabel
- FOX 36 Float Rhythm Air Grip
- 3 modes / 15x110mm QR axle / tapered steerer
- 44mm offset / Reb. Adj. / Lockout / 160mm travel
Dämpfer
- FOX NUDE 6T EVOL Trunnion
- SCOTT custom w. travel / geo adj.
- 3 modes: Lockout-Traction Control-Descend
- Low Speed Adj. / Custom large Air volume / Reb. Adj.
- Travel 155-100-Lockout / T185X55mm
Lenker-Fernbedienung
- SCOTT TwinLoc 2 Technology
- Suspension & Dropper Remote
- 3 Suspension modes
Antriebseinheit
- TQ HPR50 Mid Motor drive 50Nm max Torque
- EU: 25kmh / US: 20mph
Batterie
- TQ Internal 360Wh
Display
- TQ HPR
- Bluetooth / ANT+ / Dedicated Smartphone app
Ladegerät
- TQ 100-240V-4A
Schaltung
- Schaltwerk: Shimano XT RD-M8100 SGS / Shadow Plus / 12 Speed
- Schalthebel: Shimano Deore SL-M6100-IR / Rapidfire Plus / I-spec EV clamp
- Kurbelsatz: FSA Alloy crankset / 175mm / 34T
- Kettenführung: e*thirteen / e*spec Slider
- Kettenblatt: Scott custom spider / FSA 12Speed 34T chainring
- Kette: Shimano CN-M6100
- Kassette: Shimano CS-M6100 / 10-51T
Bremsen
- Shimano Deore M6120 4 Piston Disc
- Bremsscheibe:
- Vorne: Shimano SM-RT64 CL 203mm
- Hinten: Shimano SM-RT64 CL 203mm
Lenker
- Syncros Hixon 1.5 Alloy 7050
- Size S & M: 15mm rise / Size L & XL: 25mm rise
- back sweep 8° / 780mm
- Syncros Endurance lock-on grips
Vorbau
- Syncros AM 1.5
- Syncros Cable Integration System
- 4° rise / 7050 Alloy / 31.8mm / 1 1/8"
Sattelstütze
- Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm
- S: 140mm / M: 180mm / L: 210mm
Sattel
- Syncros Tofino 1.5 Regular / Titanium rails
Steuersatz
- Syncros - Acros Angle adjust & Cable Routing HS System
- Stainless / +-0.6° head angle adjustment
- ZS56/28.6 – ZS56/40 MTB
Naben
- Vorderradnabe: Formula CL-811 / 15x110mm
- Hinterradnabe: Formula CL-148M / 12x148mm
Speichen
- Stainless Black 15G / 1.8mm
Felgen
- Syncros X-30S / 32H / 30mm / Sleeve Joint / Tubeless ready
Reifen
- Vorne: Maxxis Dissector / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C maxx Terra
- Hinten: Maxxis Dissector / 2.6" / 60TPI Foldable / Tubeless Ready / EXO 3C maxx Terra
Extras
- Syncros Fork Fender
Gewicht
- Ca. 19.5 kg (with tubes)
- Ca. 42.99 lbs (with tubes)
Max. Systemgewicht
- 128 kg
- Das Gesamtgewicht umfasst das Bike, den Fahrer, die Ausrüstung und eventuelles weiteres Gepäck.
