| Farbe | Dunkel Blau |
| Spezial-Farbe | Dark Blue |
| Grösse | 165 x 39.5 x 87 cm |
| Einsatzbereich | Familie / Cargo |
| Gänge | |
| Rahmen | Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 180 kg |
| Gabel | Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 180 kg |
| Radgrösse | 20" |
| Radsatz | Tern Atlas H, cargo wheel |
| Kurbelgarnitur | Tern HSD custom, Gates CDX CNC machined beltring |
| Schaltwerk | n/a |
| Schalthebel | Enviolo, Twist |
| Kassette | Gates CDX, precision CNC machined cog |
| Kette | Gates Carbon Drive CDX belt |
| Lichtabgabe (Lumen) | 700 lumens |
| Leuchtdauer (Std) | 0 |
| Bremse | Magura MT4, hydraulic disc, 180, 160 mm rotor |
| Ventilart | 0 |
| Bremsscheiben | 180mm / 160mm |
| ETRO | 55-406 |
| INCH | 20" |
| Kettenführung/Kettenschutz | Tern Custom, full chain cover |
| Vorbau | Tern Andros, adjustable, forged construction |
| Lenker | Tern Sweep, 6061-AL, Tern Andros adapted |
| Steuersatz | Tern Flux Pro Taper by FSA, 1.5", angular contact bearings, Physis integrated |
| Sattelstütze | Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm |
| Körperhaltung | 0 |
| Sattel | Tern Upright by Velo |
| Bereifung | Schwalbe Big Ben, 55-406, RaceGuard puncture protection, ECE-R75 ebike certification |
| Vorderradnabe | Novatec, Thru-axle, sealed bearings |
| Hinterradnabe | Enviolo Heavy Duty, 380% continuously variable range |
| Pedalen | Urban with non-slip surface, sealed bearings |
| Schutzblech | SKS, stainless hardware |
| Gepäckträger | Atlas H rack, Atlas Rack Mount, 80 kg capacity |
| Seitenständer | Ursus, rear mount |
| Frontlicht | Ignis Headlight, Ultra wide 700 lumens, Hi/Lo Beam |
| Rücklicht | RearStop Brake Light, Always on |
| Dynamo | 0 |
| Typ | 0 |
| Schloss | ABUS, keyed-alike with Bosch battery |
| Motor | Bosch Performance, 340% Assist, 75 Nm Torque, max speed 25 kph |
| Batterie | Bosch PowerPack 545 |
| Display | Bosch Kiox 300 w/ LED remote, 4 mode selectable, walk assist, connectivity with Bosch eBike Flow app |
| Max. Systemgewicht | 180.00 Kilogramm |
| Felge | Tern Atlas H, wide 35 mm |
| Griffe/Lenkerband | Ergon |
| Gewicht | 29.4 Kilogramm |
