Rahmen
- Modell: Addict Gravel HMF Carbon
- Geometrie: Gravel geometry
- Eigenschaften: Replaceable Derailleur Hanger, Internal cable routing, Syncros fender kit ready
Gabel
- Modell: Addict Gravel HMF
- Bremsaufnahme: Flatmount Disc
- Steuerrohr: 1 1/4"-1 1/2" Eccentric Carbon steerer
Schaltung
- Schaltwerk: SRAM RIVAL eTap AXS, 24 Speed, Electronic Shift System
- Umwerfer: SRAM RIVAL eTap AXS, Electronic Shift System
- Schalthebel: SRAM RIVAL eTap AXS HRD, Shift-Brake System
Antrieb
- Kurbelsatz: SRAM RIVAL Crankset, 46/33
- Innenlager: SRAM DUB PF ROAD 86.5
- Kette: SRAM RIVAL
- Kassette: SRAM RIVAL XG1250, 10-36
Bremsen
- Modell: SRAM RIVAL eTap AXS HRD, Shift-Brake System
- Bremsscheiben: SRAM Paceline Rotor, 160mm vorne und hinten
Cockpit
- Lenker: Syncros Creston 2.0 X, Alloy, 31.8mm
- Vorbau: Syncros RR2.0, 1 1/4", vier Bolzen, 31.8mm
Sattel und Sattelstütze
- Sattelstütze: Syncros SP-R101-CF
- Sattel: Syncros Tofino Regular 2.0 Cutout
Steuersatz
- Modell: Acros AIF-1134
Laufräder
- Laufradsatz: Syncros Capital X40, Carbon, 24 Speichen vorne und hinten
- Achsen: Syncros SL Axle, abnehmbarer Hebel mit integriertem Werkzeug
Reifen
- Vorderreifen: Schwalbe G-One Bite Performance, 700x45C
- Hinterreifen: Schwalbe G-One Bite Performance, 700x45C
Gewicht
- Bike: ca. 9.2 kg (20.28 lbs)
- Maximales Systemgewicht: 120 kg
(Bike, Fahrer, Ausrüstung und weiteres Gepäck)
| XS/49 | S/52 | M/54 | L/56 | XL/58 | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | head tube angle | 70.0 ° | 70.0 ° | 71.0 ° | 71.0 ° | 71.0 ° | |||||||||
| B | head tube length | 95.0 mm | 122.0 mm | 140.0 mm | 166.0 mm | 187.0 mm | |||||||||
| C | top tube horizontal | 518.0 mm | 534.5 mm | 554.5 mm | 578.5 mm | 592.5 mm | |||||||||
| D | standover height | 759.0 mm | 786.0 mm | 807.0 mm | 828.0 mm | 847.0 mm | |||||||||
| E | BB offset | -71.0 mm | -71.0 mm | -71.0 mm | -71.0 mm | -71.0 mm | |||||||||
| F | BB height | 283.0 mm | 283.0 mm | 283.0 mm | 283.0 mm | 283.0 mm | |||||||||
| G | wheel base | 1,009.4 mm | 1,022.9 mm | 1,029.2 mm | 1,048.7 mm | 1,063.5 mm | |||||||||
| H | BB center to toptube center | 447.0 mm | 477.0 mm | 498.0 mm | 516.0 mm | 536.0 mm | |||||||||
| I | BB center to top of seattube | 477.0 mm | 507.0 mm | 528.0 mm | 546.0 mm | 566.0 mm | |||||||||
| J | seat angle | 74.5 ° | 74.0 ° | 73.5 ° | 73.0 ° | 73.0 ° | |||||||||
| K | chainstay | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm | |||||||||
| L | reach | 374.1 mm | 378.4 mm | 387.1 mm | 398.2 mm | 406.1 mm | |||||||||
| M | stack | 519.0 mm | 544.4 mm | 565.3 mm | 589.9 mm | 609.7 mm | |||||||||
| N | stem length | 83.0 mm | 93.0 mm | 103.0 mm | 103.0 mm | 113.0 mm | |||||||||
