Rahmen: Genius Carbon HMF Mainframe with Alloy 6061 Swingarm, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
BIDEX Attribut Framecolor: FC99
BIDEX Attribut Framematerial: FM40
BIDEX Attribut Frametype: FT21
Gabel: FOX 36 Float Performance Elite Grip 2 Air, HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle, 44mm offset / tapered steerer, 160mm travel
Gabel Federweg in mm: 160
Hinterbaudämpfer: FOX Float X NUDE PE EVOL Piggy Back Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Climbing-Traction Control-Descend, Custom large air volume / Comp & Reb. Adj., Travel 150-100-Climbing / T185X55mm
Federweg Dämpfer in mm: 150
Schaltung: SRAM GX Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System
Schalthebel: SRAM GX Eagle AXS Rocker Controller
Anzahl Gänge. Bei stufenlosen Schaltungen frei lassen.: 12
BIDEX Attribut Gearsystem: GS10
Bremse vorne: Shimano XT M8120 4 Piston Disc
Bremse hinten: Shimano XT M8120 4 Piston Disc
Bremsscheibe vorne: Shimano SM-RT76 / 6 Bolt / 203mm
Bremsscheibe hinten: Shimano SM-RT76 / 6 Bolt / 180mm
BIDEX Attribut Brake: BR25
Laufradsatz (Nabe, Speichen, Felgen): Syncros Revelstoke 2.0 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
Reifen vorne: Maxxis Minion DHF / 2.6" / 120TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
Reifen hinten: Maxxis Dissector / 2.6" / 60TPI Foldable, Tubeless Ready / EXO 3C maxx Terra
BIDEX Attribut Wheelsize: WS29
Lenker: Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L 25mm rise, back sweep 8° / 780mm
Steuersatz: Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Griffe: Syncros Endurance lock-on grips
Sattel: Syncros Savona 2.0 V-Concept, CrMo rails
Sattelstütze: Syncros Duncan Dropper Post 1.5, 31.6mm / S size 140mm / M size 160mm, L size 170mm
Kurbelsatz: SRAM GX Eagle Transmission, Bash guard / DUB / 55mm CL / 32T
Innenlager: SRAM DUB PF 92 MTB Wide / shell 41x92mm
von Kette oder Riemen. Ersetzt Feld chain ab V1.5: SRAM CN GX Eagle Transmission
Zahnkranz: SRAM GX Eagle XS 1275 Transmission 10-52
BIDEX Attribut Drive Types: DT10
Schutzbleche: Syncros Fork Fender
