Ransom Alloy SL 6011Custom butted / VLK Virtual 4 Link kinematic27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj.TBC Trunnion box construction / Boost 12x148mm
GabelFOX 38 Float Performance Air / GRIP / Comp Adj. / Reb. Adj. / 15x110mm QR axle44mm offset / 170mm travel
DämpferFOX NUDE T EVOL TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-Descendcustom large air volume / DPS / Reb. Adj.Travel 170-120-Lockout / 205X65mm
Lenker-fernbedienungTracLoc TechnologyRear Suspension & Dropper Remote3 Rear Suspension modes
SchaltwerkSRAM NX Eagle 12 Speed
SchalthebelSRAM NX Eagle Trigger
KurbelsatzSRAM NX Eagle DUB Boost32T
KettenführungSCOTT Chainguide
InnenlagerSRAM DUB PF integrated / shell 41x92mm
KetteSRAM CN NX Eagle
KassetteSRAM NX / PG1210 / 11-50 T
BremsenSRAM DB8 4 Piston Disc
BremsscheibeSRAM Centerline Rotors / 6 Bolt / 200/F & 180/R
LenkerSyncros Hixon 1.5 Rise / Alloy 20140D.B.20mm rise / 8° / 780mmSyncros Pro lock-on grips
VorbauSyncros XM1.5 / Alloy 6061integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
SattelstützeSyncros Duncan 2.0 Dropper Post31.6mm / S 125mm / M 150mm / L & XL 170mm
SattelSyncros Kaslo 2.0Crmo Rails
SteuersatzSyncros Pro Press Fit E2 / Tapered 1.5"-1 1/8"OD 50/62mm / ID 44/56mm
LaufradsatzSyncros Revelstoke 2.5 6 BoltF: 15x110mm, R: 12x148mm Boost30mm Tubeless ready rim 28HrSyncros Axle w/Removable Lever with Tool
VorderreifenMaxxis Assegai / 2.5" / 60TPI Foldable / EXO+ / TR / 3C Maxx Gripp
HinterreifenMaxxis Dissector / 2.4" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra
ExtrasSyncros Trail Fender 2 36/38
Gewicht in Kg (ca.)15.8 (with tubes)
Gewicht in Lbs (ca.)34.83 (with tubes)
Max. Systemgewicht128kgDas Gesamtgewicht umfasst das Bike, den Fahrer, die Ausrüstung und eventuelles weiteres Gepäck.
