RahmenSpark Carbon HMFIntegrated Suspension TechnologyFlex Pivot / Adjustable head angleSyncros Cable Integration SystemBB92 / UDH Interface / 12x148mm with 55mm Chainline
GabelFOX 34 Float Factory Air / Kashima FIT43-Modes with low Speed adj. / Kabolt 15x110mm axle / 44mm offsetTapered steerer / Lockout / Reb. Adj.130mm travel
DämpferFOX NUDE 5T Factory EVOL TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendCustom large Air volume / DPS / Kashima / Reb. Adj.Travel 120-80-Lockout / T165X45mm
Lenker-fernbedienungSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
SchaltwerkSRAM X01 Eagle AXS 12 SpeedWireless Electronic Shift System
SchalthebelSRAM GX Eagle AXS Rocker Controller
KurbelsatzSRAM X01 DUB Eagle Carbon crankarm55mm CL / 32T
InnenlagerSRAM DUB PF 92 MTB Wide / shell 41x92mm
KetteSRAM CN X01 Eagle
KassetteSRAM X01 XG1295 / 10-52 T
BremsenShimano XT M8120 4 Piston Disc
BremsscheibeShimano RT-MT800 CL / F&R 180mm
LenkerSyncros Fraser iC SL DC Carbon0° rise / back sweep 8° / mini Rise / 760mmSyncros Performance XC lock-on grips
SattelstützeFOX Transfer Factory Dropper Post Kashima31.6mm / S size 125mm / M size 140mm / L size 150mm / XL size 150mm
SattelSyncros Tofino 1.5 RegularTitanium rails
SteuersatzSyncros - Acros Angle adjust & Cable Routing HS SystemStainless, +-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
LaufradsatzSyncros Silverton 1.0-30 6 BoltF: 15x110mm, R: 12x148mm30mm Tubeless ready Carbon rim 28HDT Swiss Ratchet Hubs / XD DriverSRAM TyreWiz / Syncros SL Axle w/Removable Leverwith 6mm Allen, T30 and T25 Tools
VorderreifenSchwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Soft
HinterreifenSchwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Grip
ExtrasSRAM AXS PowerpackSRAM TyreWizSyncros Fork Fender
ZubehörSyncros Eco SealantTransport Axle
Gewicht in Kg (ca.)11.4 (Tubeless setup)
Gewicht in Lbs (ca.)25.13 (Tubeless setup)
Max. Systemgewicht128kgDas Gesamtgewicht umfasst das Bike, den Fahrer, die Ausrüstung und eventuelles weiteres Gepäck.
